General Feature
APPLICATION
Client PCs, Game Consoles
FORM FACTOR
M.2 (2280)
INTERFACE
PCIe Gen 4.0 x4, NVMe 2.0
DIMENSION (WxHxD)
80 x 22 x 2.3 mm
WEIGHT
Max 9.0g Weight
STORAGE MEMORY
Samsung V-NAND 3-bit MLC
CONTROLLER
Samsung in-house Controller
CACHE MEMORY
- Samsung 1GB Low Power DDR4 SDRAM (1TB)
- Samsung 2GB Low Power DDR4 SDRAM(2TB)
- Samsung 4GB Low Power DDR4 SDRAM(4TB)
Special Feature
TRIM SUPPORT
Supported
S.M.A.R.T SUPPORT
Supported
GC (GARBAGE COLLECTION)
Auto Garbage Collection Algorithm
ENCRYPTION SUPPORT
- AES 256-bit Encryption (Class 0) TCG/Opal
- IEEE1667 (Encrypted drive)
WWN SUPPORT
Not supported
DEVICE SLEEP MODE SUPPORT
Yes
Performance
SEQUENTIAL READ
- 1TB: Up to 7,450 MB/s
- 2TB: Up to 7,450 MB/s
- 4TB: Up to 7,450 MB/s
SEQUENTIAL WRITE
- 1TB: Up to 6,900 MB/s
- 2TB: Up to 6,900 MB/s
- 4TB: Up to 6,900 MB/s
RANDOM READ (4KB, QD32)
- 1TB: Up to 1,200,000 IOPS
- 2TB: Up to 1,400,000 IOPS
- 4TB: Up to 1,600,000 IOPS
RANDOM WRITE (4KB, QD32)
- 1TB: Up to 1,550,000 IOPS
- 2TB: Up to 1,550,000 IOPS
- 4TB: Up to 1,550,000 IOPS
RANDOM READ (4KB, QD1)
- 1TB: Up to 22,000 IOPS
- 2TB: Up to 22,000 IOPS
- 4TB: Up to 22,000 IOPS
RANDOM WRITE (4KB, QD1)
- 1TB: Up to 80,000 IOPS
- 2TB: Up to 80,000 IOPS
- 4TB: Up to 80,000 IOPS
